AI Built the Burj Khalifa in ETABS — Complete Structural Model, Analysis & Design

DOWNLOAD / GET THE PLUGIN:

https://buymeacoffee.com/utecno/e/572908


I used ETABS Codex Assistant to model the Burj Khalifa in ETABS — from the foundation system all the way to the top of the tower.

This demonstration shows how Codex can directly interact with ETABS through MCP and the ETABS API to perform a complete, multi-step structural engineering workflow using natural-language instructions.

✓ Research available engineering information about the Burj Khalifa

✓ Create the complete tower geometry from foundation to spire

✓ Generate stories, grids, structural layouts, and complex tower geometry

✓ Define concrete and steel materials

✓ Create structural sections and properties

✓ Model columns, walls, core elements, beams, slabs, and other structural components

✓ Model the foundation system

✓ Create and assign structural loads

✓ Configure mass sources and load cases

✓ Generate load combinations

✓ Run the ETABS structural analysis

✓ Review modal behavior and structural response

✓ Check displacements and story drifts

✓ Review reactions, forces, and analysis results

✓ Perform structural design operations

✓ Inspect model connectivity, assignments, warnings, and errors

✓ Modify and correct the model through Codex

✓ Execute long, multi-step ETABS workflows automatically

✓ Retrieve structured and traceable engineering results

The goal of this Burj Khalifa case study was to push the plugin beyond simple automation and test whether Codex could manage a large and highly complex ETABS project from initial modeling through analysis and design.

Where complete real-world Burj Khalifa engineering data was not publicly available, reasonable engineering assumptions were used. This demonstration should therefore not be considered the official as-built structural model of the Burj Khalifa.

━━━━━━━━━━━━━━━━━━━━━━

ETABS CODEX ASSISTANT

Control ETABS directly through Codex using natural-language instructions.

The plugin connects Codex to a locally installed ETABS application through MCP and the ETABS API, allowing structural engineers to create, modify, analyze, design, inspect, and review structural models.

━━━━━━━━━━━━━━━━━━━━━━


━━━━━━━━━━━━━━━━━━━━━━

REQUIREMENTS

✓ Windows x64

✓ Licensed ETABS installation

✓ Codex with Codex CLI available

✓ Supported ETABS API version

✓ No separate OpenAI API key is required by the plugin

━━━━━━━━━━━━━━━━━━━━━━

IMPORTANT

All structural models, loads, assumptions, analysis results, and design outputs must be independently reviewed and verified by a qualified structural engineer before being used for any real engineering project.

ETABS Codex Assistant is an independent third-party integration and is not affiliated with or endorsed by Computers and Structures, Inc. (CSI), OpenAI, or the Burj Khalifa project owners.

#BurjKhalifa #ETABS #Codex #ETABSAI #StructuralEngineering #StructuralAnalysis #StructuralDesign #ETABSPlugin #ETABSAutomation #OpenAICodex #CivilEngineering #SkyscraperDesign #EngineeringAI #MCP
